Hydraulic piston and rod seal Y 20x32x6 NBR80 up to 200 bar KVK/China
Product data
The hydraulic seal Y has a symmetrical design and is suitable for both piston and rod.
Ød=20 mm; ØD=32 mm; H=6 mm; Ød1=20.6 mm; ØD1=31.4 mm; L=8 mm
Material: NBR80
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 200 bar
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic rod seal BS 20x28x5 PU93 KVK up to 400 bar KVK/China
Product data
Ød=20 mm; ØD=28 mm; h=5 mm; HA=5.7 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral-based hydraulic oils and emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 130 pcs.
Hydraulic piston and rod seal UN 18x30x8 PU93 up to 320 bar KVK/China
Product data
Ød=18 mm; ØD=30 mm; h=8 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 20 pcs.
Hydraulic rod seal BS 18x26x5 PU93 KVK up to 400 bar KVK/China
Product data
Ød=18 mm; ØD=26 mm; h=5 mm; HA=5.7 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral-based hydraulic oils and emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 14 pcs.
Hydraulic rod seal BS 55x65x7.3 PU93 KVK up to 400 bar KVK/China
Product data
Ød=55 mm; ØD=65 mm; h=7.3 mm; HA=8 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral-based hydraulic oils and emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 100 pcs.
Hydraulic piston and rod seal UPH-45F 45x63x10 NBR90 up to 320 bar KVK/China
Product data
The hydraulic seal UPH has a symmetrical design and is suitable for both piston and rod.
Ød=45 mm; ØD=63 mm; h=10 mm; ØD1=62 mm; HA=11 mm; HB=14 mm; r=4 mm
Material: NBR90
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 150 bar, it is recommended to use a back-up ring
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 16 pcs.
Hydraulic piston and rod seal UN 45x55x7 PU93 up to 320 bar KVK/China
Product data
Ød=45 mm; ØD=55 mm; h=7 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 96 pcs.
Hydraulic piston and rod seal UN 40x60x10 PU93 up to 320 bar KVK/China
Product data
Ød=40 mm; ØD=60 mm; h=10 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 32 pcs.
Hydraulic piston and rod seal UN 40x50x5 PU93 up to 320 bar KVK/China
Product data
Ød=40 mm; ØD=50 mm; h=5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 29 pcs.
Hydraulic piston and rod seal UN 40x48x6 PU93 up to 320 bar KVK/China
Product data
Ød=40 mm; ØD=48 mm; h=6 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 98 pcs.
