Hydraulic piston seal PU-PG-55А 55x39.5x6.3 PU98+NBR70 до 350 bar KVK /China
Product data
ØD=55 mm ; Ød=39.5 mm ; H=6.3 mm ; R1max=0.8 mm ; О-пръстен: 38.5x5.3 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -30°C ~ +120°C
Media: mineral-based hydraulic oils
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 22 pcs.
Hydraulic piston seal PU-PG-50 50x39x4.2 PU98+NBR70 до 350 bar KVK /China
Product data
ØD=30 mm ; Ød=22.5 mm ; H=3.2 mm ; R1max=0.6 mm ; О-пръстен: 21.2x2.65 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -30°C ~ +120°C
Media: mineral-based hydraulic oils
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 46 pcs.
Hydraulic piston seal PU-PG-50B 50x34.5x6.3 PU98+NBR70 до 350 bar KVK /China
Product data
ØD=50 mm ; Ød=34.5 mm ; H=6.3 mm ; R1max=0.8 mm ; О-пръстен: 42.5x2.65 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -30°C ~ +120°C
Media: mineral-based hydraulic oils
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 15 pcs.
Hydraulic piston seal PU-PG-30 30x22.5x3.2 PU98+NBR70 до 350 bar KVK /China
Product data
ØD=30 mm ; Ød=22.5 mm ; H=3.2 mm ; R1max=0.6 mm ; О-пръстен: 21.2x2.65 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -30°C ~ +120°C
Media: mineral-based hydraulic oils
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 40 pcs.
Hydraulic piston seal PU-PG-125 125x109.5х6.3 PU98+NBR70 до 350 bar KVK /China
Product data
ØD=125 mm ; Ød=109.5 mm ; H=6.3 mm ; R1max=1.2 mm ; O-ring: 109x5.3 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -30°C ~ +120°C
Media: mineral-based hydraulic oils
Manufacturer:
Zhongxingshun Sealing Products Factory
Hydraulic piston seal PU-PG-125A 125x104x8.1 PU98+NBR70 до 350 bar KVK /China
Product data
ØD=125 mm ; Ød=104 mm ; H=8.1 mm ; R1max=1.2 mm ; O-ring: 102x7
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -30°C ~ +120°C
Media: mineral-based hydraulic oils
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 14 pcs.
Hydraulic rod seal RS 80х95.1х6.3 PU98 + NBR70 до 350 bar KVK/China
Product data
Ød=80 mm ; ØD=95.1 mm ; H=6.3m ; R1 max:1.2 mm ; O-пръстен: 85x5.3 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -35°C ~ +180°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 38 pcs.
Hydraulic rod seal RS 140х155.1х6.3 PU98 + NBR70 до 350 bar KVK/China
Product data
Ød=140 mm ; ØD=155.1 mm ; H=6.3m ; R1 max:1.2 mm ; O-пръстен: 145x5.3 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -35°C ~ +180°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic rod seal RS 130х145.1х6.3 PU98 + NBR70 до 350 bar KVK/China
Product data
Ød=130 mm ; ØD=145.1 mm ; H=6.3m ; R1 max:1.2 mm ; O-пръстен: 136x5.3 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -35°C ~ +180°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic rod seal RS 100х115.1х6.3 PU98 + NBR70 до 350 bar KVK/China
Product data
Ød=100 mm ; ØD=115.1 mm ; H=6.3m ; R1 max:1.2 mm ; O-пръстен: 105x5.33 mm
Material: PU98+NBR70
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 350 bar
Speed: ≤ 4.0 m/s
Temperature: -35°C ~ +180°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 14 pcs.
