New Products

Oil seal type TB (BS) with a metal outside diameter, a dust lip and a garter spring.

Material: nitrile rubber (NBR).

OE References:

Suitable for:

Manufacturer:

SO GIANT OIL SEAL INDUSTRIAL  CO., LTD

For delivery options to your country, please do not hesitate to contact us!

Hydraulic piston/rod seal with symmetrical design.

ID: 4.0 mm

OD: 12.0 mm

Width: 4.0 mm

Material: PU92

Adaptable temperature: -20 ~ 100 C

Maximum working pressure: 350 bar (35Mpa)

Manufacturer:  SO GIANT OIL SEAL INDUSTRIAL  CO., LTD

Product data

Ød=25 mm; ØD=35 mm; h=5 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=35 mm; ØD=45 mm; h=10 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=32 mm; ØD=48 mm; h=10 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=16 mm; ØD=26 mm; h=8 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Oil seal type SB (B),  without dust lip and with spring.

Material: nitrile rubber (NBR).

OE References:

Suitable for:

For reference only. We cannot guarantee 100% compatibility.Manufacturer:

SO GIANT OIL SEAL INDUSTRIAL  CO., LTD

For delivery options to your country, please do not hesitate to contact us!

Product data

Ød=14 mm; ØD=20 mm; h=5 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=12 mm; ØD=18 mm; h=4 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Oil seal type TC4 (131),  with  dust lip, with additional sealing edge and with spring.

Material: nitrile rubber (NBR).

Helix:

OE references:

Suitable for:

The nitrile rubber may vary in color from the one shown in the picture, without this affecting the sealing properties of the oil seal.

Manufacturer:  SO GIANT OIL SEAL INDUSTRIAL  CO., LTD
