Piston rod UN seals

Hydraulic piston/rod seal with symmetrical design.

ID: 18.0 mm

OD: 28.0 mm

Width: 8.0 mm

Material: PU92

Adaptable temperature: -20 ~ 100 C

Maximum working pressure: 350 bar (35Mpa)

Manufacturer:  SO GIANT OIL SEAL INDUSTRIAL  CO., LTD

Hydraulic piston/rod seal with symmetrical design.

ID: 18.0 mm

OD: 26.0 mm

Width: 5.0 mm

Material: PU92

Adaptable temperature: -20 ~ 100 C

Maximum working pressure: 350 bar (35Mpa)

Manufacturer:  SO GIANT OIL SEAL INDUSTRIAL  CO., LTD

Product data

Ød=180 mm ; ØD=210 mm ; h=22 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=120 mm ; ØD=140 mm ; h=10 mm ; HA=11 mm ; C=4 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=115 mm ; ØD=130 mm ; h=9 mm ; HA=10 mm ; C=4 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=85 mm ; ØD=95 mm ; h=12 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=85 mm ; ØD=95 mm ; h=5 mm ; HA=5.7 mm ; C=2 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=80 mm ; ØD=95 mm ; h=12 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=70 mm ; ØD=85 mm ; h=12 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

Ød=70 mm ; ØD=85 mm ; h=10 mm ; HA=11 mm ; C=4 mm

Material: PU93

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)

Manufacturer:

Zhongxingshun Sealing Products Factory
