Piston rod UN seals
Hydraulic piston and rod seal UN 140x160x10 KVK up to 320 bar KVK/China
Product data
Ød=140 mm ; ØD=160 mm ; h=10 mm ; HA=11 mm ; C=4.0 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 30 pcs.
Hydraulic piston and rod seal UN 160x180x10 KVK up to 320 bar KVK/China
Product data
Ød=160 mm ; ØD=180 mm ; h=10 mm ; HA=11 mm ; C=4.0 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 16 pcs.
Hydraulic piston and rod seal UN 105x115x9 KVK up to 320 bar KVK/China
Product data
Ød=105 mm ; ØD=115 mm ; h=9 mm ; HA=10 mm ; C=4.0 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston and rod seal UN 98x112x9 KVK up to 320 bar KVK/China
Product data
Ød=98 mm ; ØD=112 mm ; h=9 mm ; HA=10 mm ; C=4.0 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 18 pcs.
Hydraulic piston and rod seal UN 85x93x11.5 KVK up to 320 bar KVK/China
Product data
Ød=85 mm ; ØD=93 mm ; h=11.5 mm ; HA=12.5 mm ; C=4.0 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 7 pcs.
Hydraulic piston and rod seal UN 80x92x8.7 KVK up to 320 bar KVK/China
Product data
Ød=80 mm ; ØD=92 mm ; h=8.7 mm ; HA=9.7 mm ; C=2.5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 8 pcs.
Hydraulic piston and rod seal UN 65x80x9U93 KVK up to 320 bar KVK/China
Product data
Ød=65 mm ; ØD=80 mm ; h=9 mm ; HA=10 mm ; C=2.5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 45 pcs.
Hydraulic piston and rod seal UN 65x75x9 PU93 KVK up to 320 bar KVK/China
Product data
Ød=60 mm ; ØD=75 mm ; h=9 mm ; HA=10 mm ; C=2.5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 12 pcs.
Hydraulic piston and rod seal UN 60x68x11.5 PU93 KVK up to 320 bar KVK/China
Product data
Ød=60 mm ; ØD=68 mm ; h=11.5 mm ; HA=12.5 mm ; C=2.5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston and rod seal UN 56x66x6.5 PU93 KVK up to 320 bar KVK/China
Product data
Ød=56 mm ; ØD=66 mm ; h=6.5 mm ; HA=7.5 mm ; C=2.5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
